Screw conveyors, stainless steel

Screw conveyors, stainless steel

The screw conveyor is perhaps the most common type of conveyor used for powdered materials. Indeed, these have been in our product range from the very beginning.

Although the screw conveyor structure always depends on the application and properties of the material being handled, our conveyors are primarily manufactured on the basis that the conveyor bearings are outside the seal housings, the axle lead-throughs are pneumatically sealed, and the spiral pitches are progressive.

Our screw conveyors are suitable for conveying nearly every type of powdered and granular material. The conveyors are available in epoxy-coated carbon steel or coated stainless steel.

FEATURES:

  • Dosing/conveyor capacities: 10-50,000 kg/h
  • Lengths: 0.5-10 m
  • Incline: 0-90°
  • Structural materials: stainless steel AISI304
  • Progressive spiral pitches
  • Pressurised seal housings in the axle lead-throughs
  • FDA approvel bearings
  • ATEX 21 classification on request
  • Dosing/conveying to one or more points

APPLICATIONS:

  • Powder dosing and conveying
  • Dosing with a screw conveyor from a BIG-BAG into a container, mixing bowl, intermediate scale, etc.
  • Precise dosing micro ingredients
